Inconel 600 tube fittings, crafted from a nickel-chromium alloy (UNS N06600), deliver outstanding resistance to high-temperature oxidation, carburization, and chloride-induced stress corrosion cracking. These fittings excel in harsh environments like chemical processing and aerospace, providing leak-free seals with superior mechanical strength and thermal stability.
Nickel Alloy 600 Female Branch Tee Exporter, UNS N06600 45 Degree Male Elbow, DIN 2.4816 Union Tee in Mumbai, India.
Kalpataru Piping Solution serves as a premier manufacturer, supplier, and distributor of Inconel 600 fittings, engineered for superior performance in high-stakes industrial applications. These fittings exhibit exceptional corrosion resistance, mechanical strength, and thermal stability, making them ideal for sectors such as chemical processing, power generation, and marine engineering. Our product line includes precise configurations like the 3/8 in. Tube OD x 3/8 in. Male NPT, each subjected to stringent testing to ensure reliability under extreme pressures and temperatures. Distinguished by their advanced sealing mechanisms and durable construction, Inconel 600 fittings provide robust solutions that maintain integrity in aggressive environments, supporting seamless operational efficiency.
ASME SB366 Inconel 600 Male Run Tee, Inconel Alloy 600 Union Cross, Inconel 600 Double Ferrule Tube Fittings Exporter in India.
Our diversity of DIN 2.4816 Reducing Union Fittings is being used to join the ends of two tubes or pipes of different diameters. Inconel 600 Bulkhead Union Fittings is highly durable, resistant to corrosion and provides high end functionality. Inconel 600 Bulkhead Reducing Union Fittings are a kind of pipe fittings that has a T-shaped by means of two open outlets on it. Inconel 600 Union Elbow Fittings are at a point to join the concrete main pipe line. Obtained in different specifications, sizes, grades and thickness, UNS N06600 Bulkhead Elbow Fittings are widely used in diverse applications in industries such as chemical processing, petrochemical, oil & gas, and so on.
Inconel 600 Tube Fittings Specification
The specifications of Inconel 600 tube fittings define their chemical, mechanical, and dimensional standards, ensuring consistent performance and reliability under extreme conditions.
| Specifications | ASTM B366 / ASME SB 366 |
| Size | 1/16” 1/2” & 1.5MM to 38.1MM |
| Thread | NPT, PT, BST, NPS, PS, BSP |
| Pressure | 6000PSI for Stainless Steel 300/1000/3000PSI for Brass |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
Inconel 600 Tube Fittings Types
Inconel 600 tube fittings come in a wide array of types, including unions, elbows, tees, crosses, and caps, each designed to meet specific piping and instrumentation requirements.
ASTM B564 UNS N06600 Tube Fitting Features
ASTM B564 UNS N06600 tube fittings exhibit several key characteristics that enhance their suitability for demanding industrial applications, including
- Maintains strong weldability across varying temperature conditions.
- Offers resistance against stress corrosion cracking caused by chloride exposure.
- Provides superior protection from corrosion, even in ultra-pure water systems.
- Exhibits excellent resistance to oxidation at elevated temperatures.
- Delivers robust defense against corrosion in caustic (alkaline) environments.
Material of Construction for Alloy 600 Tube Fittings
Alloy 600 tube fittings are manufactured from a high-performance nickel-chromium-iron alloy (UNS N06600) known for its excellent resistance to oxidation, corrosion, and stress corrosion cracking across a wide temperature range. This composition ensures durability and reliability in demanding industrial environments.
| Component | Material | Marking |
|---|---|---|
| 4 Body | DIN-2.4816 | “B564” on neck |
| 3 Front ferrule | SB 564 UNS N06600 | “B564” on outer rim |
| 2 Back ferrule | Inconel-600 | “254” or “6HN” on outer rim |
| 1 Nut | Alloy-600 | Notched hex, “B564” on face |
Size Range of Alloy 600 Instrumentation Tube Fittings
Alloy 600 instrumentation tube fittings are available across diverse size ranges, designed to meet the exact needs of precision instrumentation and control systems.
| Imperial sizes | Metric sizes |
|---|---|
| 1/8 in. | 4 mm |
| 1/16 in. | 3 mm |
| 1/4 in. | 8 mm |
| 3/16 in. | 6 mm |
| 1 1/2 in. | 12 mm |
| 3/8 in. | 10 mm |
| 5/16 in. | 18 mm |
| 5/8 in. | 16 mm |
| 1/2 in. | 25 mm |
| 1 in. | 20 mm |
| 3/4 in. |
Stock Sizes of Inconel 600 Compression Tube Fittings
Our stock of Inconel 600 compression tube fittings includes standardized sizes for quick availability, supporting efficient installation in critical process environments.
| Tube Fittings Types | Forms of Tube Fittings | Size OD | Size Inch |
|---|---|---|---|
| Tube To Union | Union Tee, Bulkhead Union, Union Elbow, Reducing Elbow, Union, Union Cross, Union Tee, Bulkhead Union, Union Elbow, Reducing Elbow, Union, Union Cross | 6mm to 38mm | 1/4″ to 1 1/2″ |
| Tube to Male Fittings | Male Connector, Male Bulkhead Connector, Male Elbow, Male Run Tee, Male Branch Tee, Male Connector, Male Bulkhead Connector, Male Elbow, Male Run Tee, Male Branch Tee | ||
| Tube to Female Fittings | Female Connector, Female Bulkhead Connector, Female Run Tee, Female Branch Tee, Female Connector, Female Bulkhead Connector, Female Run Tee, Female Branch Tee | ||
| Tube to Pipe Fittings | Female Elbow, Street Elbow, Allen Key, Bushing, Female Cap, Female Cross, Female Elbow, Female Tee, Hex Coupling, Hex Nipple, Male Elbow, Male Female Adapter, Male Female Branch Tee, Male Tee, Reducing Hex Coupling, Reducing Hex Nipple, Street Elbow, Street Tee, Union Joint Ball, Female Elbow, Street Elbow, Allen Key, Bushing, Female Cap, Female Cross, Female Elbow, Female Tee, Hex Coupling, Hex Nipple, Male Elbow, Male Female Adapter, Male Female Branch Tee, Male Tee, Reducing Hex Coupling, Reducing Hex Nipple, Street Elbow, Street Tee, Union Joint Ball | ||
| Tube Fittings Accessories | Blanking End, Blanking Plug, Tube Nut, Front Ferrule, Back Ferrule, Blanking End, Blanking Plug, Tube Nut, Front Ferrule, Back Ferrule |
Dimensions of UNS N06600 Instrument Fittings
UNS N06600 instrument fittings are manufactured to strict dimensional tolerances, ensuring seamless integration and consistent performance in high-pressure applications.
Exporter of Alloy 600 High Pressure Compression Fittings in Different Sizes and Forms
| Thread Designation (in.) | OD (inch) | OD (fraction inch) | Thread/inch NPT | Thread/inch BSP |
|---|---|---|---|---|
| 1/16 | 0.03125 | 5/16 | 27 | 28 |
| 1/2 | 0.0840 | 27/32 | 14 | 14 |
| 1/4 | 0.0540 | 35/64 | 18 | 19 |
| 5 | 5.0563 | 5-5/8 | 8 | 11 |
| 3/4 | 1.0050 | 1-3/64 | 14 | 14 |
| 3/8 | 0.0675 | 43/64 | 18 | 19 |
| 1-1/4 | 1.0660 | 1-21/32 | 11-1/2 | 11 |
| 1-1/2 | 1.0900 | 1-29/32 | 11-1/2 | 11 |
| 1/8 | 0.0405 | 13/32 | 27 | 28 |
| 1 | 1.0315 | 1-5/16 | 11-1/2 | 11 |
| 2-1/2 | 2.0875 | 2-7/8 | 8 | 11 |
| 3 | 3.05 | 3-1/2 | 8 | 11 |
| 2 | 2.0375 | 2-3/8 | 8 | 11 |
| 3-1/2 | 4.00 | 4 | 8 | 11 |
| 6 | 6.0625 | 6-5/8 | 8 | 11 |
| 4 | 4.05 | 4-1/2 | 8 | 11 |
NPT Threads Dimensions of Inconel 600 Tube Union
The NPT threads in Inconel 600 tube unions conform to industry standards, providing secure, tapered connections designed to withstand high pressures and ensure leak-proof performance.
| NPT Threads Dimensions | |||||
|---|---|---|---|---|---|
| NPT Thread | Dash Size | Female Thread ID | Male Thread MINOR OD | ||
| Size | SIZE | inch | mm | inch | mm |
| 1/4 – 18 | -4 | 0.44 | 11,2 | 0.52 | 13,2 |
| 1/8 – 27 | -2 | 0.33 | 8,4 | 0.39 | 9,9 |
| 3/8 – 18 | -06 | 0.58 | 14,7 | 0.65 | 16,6 |
| 3/4 – 14 | -12 | 0.92 | 23,4 | 1.02 | 26,0 |
| 1/2 – 14 | -8 | 0.70 | 17,8 | 0.81 | 20,6 |
| 1 – 11 1/2 | -16 | 1.16 | 29,5 | 1.28 | 32,5 |
| 1 1/2 – 11 1/2 | -24 | 1.73 | 43,9 | 1.86 | 47,3 |
| 1 1/4 – 11 1/2 | -20 | 1.5 | 38,1 | 1.62 | 41,2 |
| 2 – 11 1/2 | -32 | 2.22 | 56,4 | 2.33 | 59,3 |
| 3 – 8 | -48 | 3.34 | 84,8 | 3.44 | 87,3 |
| 2 1/2 – 8 | -40 | 2.72 | 69,1 | 2.82 | 71,5 |
BSPT & BSPP Threads Dimensions of Inconel 600 Male Elbow
BSPT and BSPP threads on Inconel 600 male elbows are engineered to precise tolerances, offering reliable sealing and compatibility with international piping systems.
| BSPT & BSPP Threads Dimensions | Dash | BSPP Male | BSPT Male | BSPP Female | BSPT Female |
|---|---|---|---|---|---|
| Size | SIZE | Thread OD | Thread OD | Thread ID | Thread ID |
| Inch – TPI | Inch | mm | Inch | mm | |
| 3/8 – 19 | -6 | 0.65 | 16.5 | 0.64 | 16.3 |
| 1/4 – 19 | -4 | 0.51 | 13.0 | 0.5 | 12.8 |
| 1/2 – 14 | -8 | 0.82 | 20.8 | 0.8 | 20.4 |
| 3/4 – 14 | -12 | 1.04 | 26.3 | 1.02 | 25.9 |
| 5/8 – 14 | -10 | 0.9 | 22.8 | 0.89 | 22.5 |
| 1 – 11 | -16 | 1.3 | 33.1 | 1.28 | 32.6 |
| 1.1/2 – 11 | -24 | 1.88 | 47.7 | 1.85 | 47.0 |
| 1/8 – 28 | -2 | 0.38 | 9.6 | 0.37 | 9.5 |
| 1.1/4 – 11 | -20 | 1.64 | 41.8 | 1.62 | 41.1 |
| 2(11) | -32 | 2.34 | 59.5 | 2.31 | 58.6 |
| 3 – 11 | -48 | 3.46 | 87.9 | 3.41 | 86.6 |
| 2.1/2 – 11 | -40 | 2.95 | 75.1 | 2.92 | 74.1 |
Thread Types of Alloy 600 Compression Tube Fittings
Alloy 600 compression tube fittings feature a variety of thread types including NPT, BSPT, BSPP, and UNF, tailored for versatile applications and optimal sealing effectiveness.
| K = BSP/ISO-Taper | BS21, ISO7/1 |
| BR = ISO-Parallel/BSP | DIN-3852 Form B(3), ISO-228/1+2, BS2779 |
| R = ISO-Parallel/BSP | DIN-3852 Form A(2), ISO-228/1+2, BS2779 |
| M = Metric Thread | ISO-6149-2 |
| N = National Pipe Taper | ANSI B1.20.1 |
| GC = BSPP Gauge Connector | B2779, ISO-228/1+2, DIN-3852 |
| RED = BSPP/ISO-Parallel | BS2779, DIN-3852, ISO-228/1+2 with elastic sealing washer(4) |
Pressure Ratings of Nickel Alloy 600 Tube to Union
Nickel Alloy 600 tube-to-union fittings are rated to withstand high pressures, ensuring reliable performance in critical industrial applications and demanding environments.
| NPT/ISO Size (inch) | Inconel 600 Tube Fitting | |
|---|---|---|
| Male PSIG (BAR) |
Female PSIG (BAR) |
|
| 1/16 | 11 000 (757) | 6 700 (461) |
| 2 | 3 900 (268) | 3 900 (268) |
| 1/4 | 8 000 (551) | 6 600 (454) |
| 1/2 | 7 700 (530) | 4 900 (337) |
| 3/4 | 7 300 (502) | 4 600 (316) |
| 3/8 | 7 800 (537) | 5 300 (365) |
| 1 1/4 | 6 000 (413) | 5 000 (344) |
| 1/8 | 10 000 (689) | 6 500 (447) |
| 1 1/2 | 5 000 (344) | 4 600 (316) |
| 1 | 5 300 (365) | 4 400 (303) |
Temperature Range of Inconel Alloy 600 Bulkhead Union
Inconel Alloy 600 bulkhead unions maintain structural integrity and functionality across a broad temperature range, from cryogenic to high-heat conditions.
| Connection Size of Swagelok End | At max temp 1000°F (537°C) ASME B31.3 | At max temp 900°F (482°C) ASME B31.1 | Up to 100°F |
|---|---|---|---|
| 1/2 | 1785 psig | 2907 psig | 5100 psig |
| 3/8 | 2275 psig | 3705 psig | 6500 psig |
| 1/4 | 3570 psig | 5814 psig | 10 200 psig |
| 6 mm | 234 bar | 381 bar | 670 bar |
| 12 mm | 108 bar | 176 bar | 310 bar |
| 10 mm | 133 bar | 216 bar | 380 bar |
Chemical Composition of Inconel DIN 2.4816 Ferrule Fittings
The chemical composition of Inconel DIN 2.4816 ferrule fittings consists primarily of nickel, chromium, and iron, formulated to deliver excellent corrosion resistance and high-temperature durability.
| Element | Description | Composition (%) |
|---|---|---|
| Ni | Nickel | 72.00 min |
| Cr | Chromium | 14.00 – 17.00 |
| Fe | Iron | 6.00 – 10.00 |
| C | Carbon | 0.15 max |
| S | Sulfur | 0.015 max |
| Si | Silicon | 0.50 max |
| Cu | Copper | 0.50 max |
| Mn | Manganese | 1.00 max |
Mechanical Properties of Inconel 600 Street Tee
Inconel 600 street tees exhibit high tensile and yield strength, combined with good ductility, making them suitable for demanding mechanical and thermal applications.
| Yield Strength 0.2% Proof (MPa) |
Tensile strength (MPa) |
Elongation (% in 50mm) |
Hardness (HRB) |
|
|---|---|---|---|---|
| MIN | 240 | 550 | 30.00 | |
| MAX | 88 |
Physical Properties of Ni Alloy 600 Male Run Tee
Ni Alloy 600 male run tees possess distinctive physical properties such as high density and elevated melting point, supporting robust performance in harsh environments.
| Melting Range | °C | 1354-1413 |
|---|---|---|
| °F | 2470-2575 | |
| Specific Heat | J/kg-°C | 444 |
| Btu/lb°F (J/kg°C) | 0.106 | |
| Electrical Resistivity | μΩ-m | 1.03 |
| ohm-circ mil/ft | 620 | |
| Permeability | 200 oersted (15.9 kA/m) | 1.01 |
| Density | Mg/m³ | 8.44 |
| lb/in³ | 0.305 | |
| Curie Temperature | °C | -124 |
| °F | -192 |
Equivalent Grades of Inconel Alloy 600 Single Ferrule Fittings
Equivalent grades of Inconel Alloy 600 single ferrule fittings align with international standards, ensuring global compatibility and consistent quality across markets.
| Grade | North America | France | Germany | Japan | Russia | European | Russian | British | Other Names |
|---|---|---|---|---|---|---|---|---|---|
| Inconel 600 | UNS N06600 | AFNOR NC15FE11M | WNR/DIN 2.4816 | JIS NCF 600 | GOST XH60BT | EURONORM NiCr15Fe | OR ЭИ868 | BS NA 14 | Alloy 600/ Nickel 600 |
UNS N06600 High Pressure Fittings Installation Guide
The installation guide for UNS N06600 high pressure fittings provides essential procedures and best practices to ensure secure, leak-proof assembly and optimal performance under demanding conditions.
| Type | Installation Description |
|---|---|
| UNS N06600 Street Elbow | Threaded, Male to Female, Round Head |
| Alloy 600 Cross | Single Ferrule, Sleeve Type, Metric Thread |
| ASTM B564 UNS N06600 Female Thread Elbow | Threaded, Round Head |
| Nickel Alloy 600 Branch Reducing Tee | BSPT, UNF, NPT, 3000-6000 Psig Pressure, Double Ferrule |
| DIN 2.4816 Female Run Tee | Round Head, Threaded |
| Inconel 600 Bulkhead Union Elbow | Metric Thread, Single Ferrule, Sleeve Type |
| Inconel 2.4816 Bulkhead Union | NPT, UNF, BSPT, 3000-6000 Psig Pressure, Double Ferrule |
| SB 564 UNS N06600 Male Street Tee | Metric, BSP, NPT, Threaded, JIC |
| Inconel Alloy 600 Tube Nuts | Double Ferrule, 3000-10000 PSI Pressure, Port Size: 1/16″ to 1 1/2” |
Certificates of Alloy 600 Pneumatic Fittings
Alloy 600 pneumatic fittings are supplied with comprehensive certifications, including material test reports and compliance with international standards, to ensure quality, traceability, and reliability in critical applications.
- ✅ Commercial Invoice including HS Code
- ✅ Certificate of Origin
- ✅ Fumigation Certificates
- ✅ NABL approved Laboratory Test Reports
- ✅ Packing List
- ✅ MTC as per EN 10204 3.1, EN 10204 3.2
- ✅ Letter of Guarantee
- ✅ Raw Material Test Reports
- ✅ NACE MR0103, NACE MR0175
- ✅ Welding Procedure Record
- ✅ Heat Treatment Charts
- ✅ Quality Assurance Plan (QAP)
- ✅ MATERIAL TRACEABILITY RECORDS
Applications of Inconel 600 High Pressure Tube Fittings
Inconel 600 high pressure tube fittings are extensively utilized across a diverse range of industries due to their exceptional resistance to corrosion, high temperatures, and mechanical stress, making them indispensable in critical and demanding environments. Their industrial applications include:
- Jet Engines
- Aerospace
- Submarine Components
- Oil and Gas
- Marine
- Heat Exchangers
- Chemical Processing
- Nuclear Power
- Waste Processing
HS Code of Inconel 600 JIC Fittings
The HS Code classification facilitates standardized customs procedures and smooth international trade for Inconel 600 JIC fittings.
| Product Description | HS Code |
|---|---|
| Inconel 600 JIC Fittings | 74122090 |
